Fast Installation Curved LED Display Slim Rental Stage 60 Hz Frame For Events-Creative customization -Shenzhen Mega Light Display Limited

Fast Installation Curved LED Display Slim Rental Stage 60 Hz Frame For Events

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Mega
Certification:	CCC, CE, ROHS
Model Number:	Indoor P3.91mm

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotation
Packaging Details:	flight case ( road case ) ; export wooden case
Delivery Time:	15 ~ 25 working days
Payment Terms:	T/T , Western Union , MoneyGram
Supply Ability:	1000Sqm / Month

Quick Quotation >

Detailed Product Description

Product Name:	Curved LED Display	Certification:	CCC, CE, ROHS
IP Rate:	43	Working Vlotage:	AC 100V - 240V
Display Function:	Video	Cabinet Size:	500mm * 500mm / 500mm * 1000mm

Fast Installation Curved LED Display Slim Rental Stage 60 Hz Frame For Events

Lightweight The aluminum die-casting technology makes the single cabinet as light as 14KG.
Ultra thin The thinnest point of the cabinet is only 75mm, making it easily to be fitted in small room.
Easy to install No need of other tools. It takes 15 minutes for 2workers to finished 30 sqm installation.
High IP The IP43 insures the reliable operation in severe environment.
Easy to maintain No need to disassemble the whole screen for maintenance. Each component can be detach individually for that purpose.
Noiseless The aluminum structure requires no fan. Combined with the noiseless power supply, the cabinet is totally silent.
Ghost canceling Exquisite and clear picture quality with no ghost. Both upstream and downstream ghosts can be automatically canceled.
High refresh rate 3840Hz refresh rate to ensure the picture wrinkle-less, lineless and stable.
Low brightness and high gray scale 14Bit-16Bit gray scale to bring excellent performance when brightness reduced to 20%.

This series products are widely applied to stage show, concert, TV station, Brand presentation, stadium display screen and so on

Indoor slim rental P3.91, P4.81, P5.68, P5.95, P6.25, P8.928mm models (unit module size: 250mm * 250mm and unit cabinet size: 500mm * 500mm)
LED Module	Pitch/mm	PH3.91	PH4.81	PH5.68	PH5.95	PH6.25	PH8.928
	Module size/mm	250*250	250*250	250*250	250*250	250*250	250*250
	Density of pixel/(dots/m2)	65536	43264	30976	28224	25600	12544
	Pixel composition	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
	Led encapsulation	SMD 3 IN 1	SMD 3 IN 1	SMD 3 IN 1	SMD 3 IN 1	SMD 3 IN 1	SMD 3 IN 1
	Resolution of module	64*64	52*52	44*44	42*42	40*40	28*28
LED Screen	Optimum viewing distance	3~38M	3~38M	4~40M	4~40M	5~45M	7~50M
	View angle	H:±160°;V±120°	H:±160°;V±120°	H:±160°;V±120°	H:±160°;V±120°	H:±160°;V±120°	H:±160°;V±120°
	Average power consumption	600W/sqm	600W/sqm	400W/sqm	400W/sqm	300W/sqm	300W/sqm
	Max power consumption	1600W/sqm	1600W/sqm	1000W/sqm	1000W/sqm	900W/sqm	700W/sqm
	Module quantity	2* 2pcs
	Size of cabinet/mm	500*500
	Resolution of cabinet	128*128	104*104	88*88	84*84	80*80	56*56
	Cabinet Material	die-casting aluminum cabinet
	Weight of cabinet	7.5Kg
	Driving method	1/16 scan constant current	1/13 scan constant current	1/11 scan constant current	1/7 scan constant current	1/10 scan constant current	1/7 scan constant current
	Frame frequency / Hz/S	≥60
	Refresh frequency/ Hz/S	800~2000
	Brightness	1500cd/m2	2000cd/m2	1500cd/m2	1500cd/m2	1500cd/m2	2500cd/m2
	Operating temperature	–20C°~60C°
	Storage temperature	–40C°~70C°
	Operation humidity	10%-90%
	Storage humidity	10%-90%
	IP Rrating (Front/Rear)	IP54/ IP43
	Working vlotage	AC220V / AC110V ±10%
	Grey scale/color depth	displaying colors≥16.7M(synchronized); 14bits
	Brightness adjustment	256 levels of each color(manually)
	Input signal	RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
	Control system	linsn/Colorlight/Nova(sending card,receiving cards and Hubs)
	Average of non-failure life	≥50,00h
	Life span	≥100,000h
	Functionaless dot rate	≤0.0001
	Control distance	CAT cable: 100m; Muti-mode fiber: 500m; Single-mode fiber: 15km

Fast Installation Curved LED Display Slim Rental Stage 60 Hz Frame For Events
