Indoor P3mm SMD LED Module 64x64dots

  • Model:P3-I-64X64
  • SMD LED Display Module
  • CE,RoHS,FCC Approved
  • 5 Years Warranty
  • Product description: Indoor P3mm SMD LED Module 64x64dots 192mmx192mm LED Display Module. Indoor SMD LED Module , We offer High quality, with Factory Price.

PH3mm SMD Indoor LED Display Module-64X64dots,192mmx192mm

Remark:

1. LED Module Including the Data & Power Cables.

2. Epistar LEDs, 5 Years Warranty, Ship in 24 hours,Free Online Support.

3. LED Module Can Work With Linsn,Novastar,Colorlight,Xixun LED Conrol Card Etc.

Model

P3-64X64

1.LED

Indoor P3mm SMD LED Module 64x64dots

Color

Package

Intensity

View Angle

Wavelength

Test Cond.

Red

SMD 2121

150mcd

140/140

620nm

25℃,20mA

Green

SMD 2121

400mcd

140/140

520nm

25℃,20mA

Blue

SMD 2121

100mcd

140/140

470nm

25℃,20mA

2.LED Module

Indoor P3mm SMD LED Module 64x64dots

Module Front View

Indoor P3mm SMD LED Module 64x64dots

Module Back View


Resolution

64(H)×64(V)


Pitch

3mm


Density

111,111 pixels/


LED Arrangement

SMD2121


Driver Mode

Dynamic 1/16 Duty constant current


Size

192mm×192mm


Mask

Pure Black mask-high contrast screen


3.Electricity Parameter


Optical Ratings


Brightness

≥1000cd/


View Angle

140 degree ( horizontal)  140degree(vertical)


View Distance

3m-30m


Gray Scale

8bits input, correction with 16bits


Display Color

16.7M


Brightness Adjustment

100 levels


Power Supply


Operation Power

AC100-240V 50-60HZ  Switch-able


Maxim Power Consumption

900 W/m2


Average Power Consumption

500 W/m2


Control System


Correction Scale Level

16bits


Frame Update Frequency

60Hz


Screen Refresh Frequency

480Hz


Gamma Correction

-5.0—5.0


Support Input

Composite Video, S-Video, DVI, HDMI., SDI, HD_SDI

Control Distance

Ethernet cable 100m, optical fiber 5km


Support VGA Mode

800×600,1024×768,1280×1024,1600×1200


Color Temperature

5000-9300 adjustable


Brightness Correction

dot by dot, module by module, cabinet by cabinet


Reliability


Operating Temp.

-20-60 Celsius degree


Operating Humidity

10-95% RH


Operating Life

100,000 hours


MTBF

5000 hours


Continuous Working Time

≥48 hours


Protection Level

IP54


Out of Control Pixel Rate

0.01%


Shipping & Payment Terms:

Delivery time: Deliver in 24 hours after received the payment.
Payment terms: Paypal/Western Union or Wire Transfer 100% before shipment.
Packaging: Strong Cardboard Carton.
Warranty: 5 Years Warranty.
Shipping method: Ship the led display module by DHL, UPS, Fedex and EMS.
Shipping cost: We will check the best shipping cost for you after you tell us the quantity and shipping address.
