Aluminum Alloy Slim Mobile LED Screen Hire P5 Programmable Taxi Top LED Display-Mobile LED Screen-Shenzhen Mega Light Display Limited

Aluminum Alloy Slim Mobile LED Screen Hire P5 Programmable Taxi Top LED Display

Product Details:

Place of Origin:	China
Brand Name:	Mega
Certification:	UL CE ROHS ISO ETL SGS SAA Fcc EMC
Model Number:	T5

Payment & Shipping Terms:

Minimum Order Quantity:	1 Square Meter
Price:	Negotiation
Packaging Details:	Wooden box or Flight case
Delivery Time:	4-6 work days
Payment Terms:	Wooden box or Flight case
Supply Ability:	3,000 units per month

Quick Quotation >

Detailed Product Description

Usage:	Outdoor	Tube Chip Color:	Full Color
Module Pixel:	32*32 Dots	MTBF:	≥10,000hours
Working Humidity:	5%-95%	Brightness:	7500CD
Viewing Angle:	160°H/120°V
High Light:	mobile advertising led display , mobile led screen

Mobile led screen hire Aluminum Alloy Slim P5 Taxi LED Display Programmable with 3G / WIFI / GPS / USB Wireless

Features:

Aluminum alloy casing with ultra thin
Outdoor Taxi Roof Video Led Display with ultra thin and light design, made of aluminum alloy casing to

reduce the weight of the display and the space, thereby it greatly decreased the weight-bearing. In addition, the full metal jacket design can effectively prevent the display splash screens,

shaking screen phenomenon.What is more , its electromagnetic shielding is also perfect!

Well Designed Cooling System
Outdoor taxi roof video led full color display has special cooling system design.The air goes inside

from the heading direction and soon form the air flow inside the display as below illustration shows

and two fans at the back-end of the display will pull the air which will make the equipment work more

reliable in high temperature and high humidity environments.

IP 65 design & Long Lasting Display double sides
Outdoor Taxi Roof Video Led Display With IP65 Waterproof rate, :rain-proof,lightning protection,shockproof,Module design,Easy installation and maintenance, It Can work

under the complex outdoor environment.

3G High Speed data Transferring
Outdoor taxi roof video led full color display has amazing data transferring speed. For expample a 100

MB Video File only needs 2 minutes to upload to the screen.

Technological Parameters:

Numbers	Technical indexes	P5 Car roof LED Video Screen
Numbers	Technical indexes	P5 Car roof LED Video Screen
1	Pixel pitch	5mm
2	Module size	160mm× 160mm
3	Module resolution	32× 32
4	Module density	40, 000dots/sqm
5	Pixel configuration	RGB ( SMD 3 in 1 )
6	Red wavelength	625± 2nm
7	Green wavelength	525± 2nm
8	Blue wavelength	470± 2nm
9	Colors	16777216
10	Best viewing distance	more than 5 m
11	Horizontal viewing angle	140°
12	Vertical viewing angle	70°
13	Maximum power consumption	≤ 1200W/m2
14	Brightness	≥ 5000cd/m2
15	Gray scale	16bits of per color
16	Color temperature	6500K
17	Control method	Asynchronization with 3G
18	Driving method	1/8 scanning
19	Frame frequency	60Hz
20	Refresh frequency	≥ 2000 Hz
21	Working voltage	AC220V/110V± 10%
22	IP grade	IP65
23	Working temperature	-20° C~80° C
24	MTBF	More than 10, 000 hours
25	Life span	More than 100, 000hours
