Place of Origin: | China |
Brand Name: | Mega |
Certification: | UL CE ROHS ISO ETL SGS SAA Fcc EMC |
Model Number: | P10 RGB |
Minimum Order Quantity: | 1 Square Meter |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden box or Flight case |
Delivery Time: | 4-6 work days |
Payment Terms: | L/C T/T Western Union Paypal Credit Card, MoneyGram, VISA |
Supply Ability: | 5,000 square meters per month |
Detailed Product Description
Warranty Time: | 5 Years | Module: | 320mm X 160mm |
---|---|---|---|
Tile Resolution: | 32 X 16 Pixels | IP Rating(Front/Rear): | IP65/IP54 |
Screen Size: | 1280*960mm/960mm*960mm | Brightness: | > 9000 Cd/m2 |
Color: | R G B ( DIP 346 ) | Apply: | Outdoor, Billboard, Adversiting |
Function and Technology Character Introduction:
1. Perfect Display Effect
High brightness and clearly display effect with easy use control system which allow you easy become enviable led display experts.
2. Attractive Factory Price
We are a professional manufacturer, has its own factories and production lines. Our price is more competitive, quality is more reliable.
3. Good After-sale Service
We offer a 1-3 year warranty service, and to provide free technical guidance. We have a professional service team; they are always online waiting to serve you.
4. CE, ISO 9001, ISO 14001 Certification
All our products have CE, ISO 9001 and ISO 14001 certification. Meet most countries request on import. According to the customer's requirements, we also could provide the certificate of origin.
1R1G1B P10 alibaba outdoor full color p10 led display video
SPECIFICATIONS Parameters:
Technical parameter | |
Module size | 320*160mm |
Pixel pitch | 10mm |
Pixel density | 10,000dots/m2 |
Pixel configuration | 1R1G1B |
Led specification | Φ3ellipse |
Pixel resolution | W:16dots*H:16dots |
Dimension | 960mm*960mm*150mm |
Quantities of module | 36pcs |
Power supply | 6pcs |
Thermal discharge | Fan*2pcs |
Total weight | 50kg |
Best viewing distance | 10-100m |
Temperature | Storage: -35°C~+85°C |
Working: -35°C~+85°C | |
Thickness | 15cm can adjustable |
Remarks: cabinet size can changed, upon project need. | |
Working voltage | AC220V/110V±10% |
Average power consumption | 300-400W |
Max. Power consumption | ≤1000W/sqm |
Current | ≤20mA(single LED) |
CPU | Pentium4 or above |
Operating system | WIN98/2000/NT/XP |
Control method | Synchronization |
Driving device | 1/4scanning |
Drive type | Constant Current driver IC |
Refresh frequency | ≥400Hz |
Grey scale/colors | 256 levels of each color(R/G/B)/16.7M color |
Brightness of white balance | More than 8000cd/sqm |
Brightness adjustment | 256 levels of each color(R/G/B)by software |
Operating ambient humidity | 10%--95% |
Video signal | PAL/NTSC |
Control system | DVI display card+full color controller card |
MTBF | ≥10,000hours |
Life span | ≥100,000hours |
Flatness | Tolerance of interpixel ≤0.3mm |
Tolerance of modules clearance≤0.6mm | |
Power switch | Automatic switch |
Display mode | 1024*768 |
LED media player |
1. High brightness and be adjustable. Built-in functional card support brightness automatically adjustment.
2. A turn-key solution including professional sports software and hardware.
3. Rich advertising LED display screen engineering experience both in domestic and oversea market.
4. Elnor product stability through strict quality control system.
5. Price Advantage: Best competitive price for Elnor outdoor led display module.
6. Performance Advantage: Best equality, high consistency, High refresh rate, high consistency, Best brightness, big viewing angle...
7. Quality advantage: From material to finished product, from design to produce, we control all steps, include the guarantee of the quality and reliability.
8. Service advantage: with professional service team for 24 hours service, Better service at same situation, better cooperation at same service.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
